“The concept for LUCI started with a little girl in a power wheelchair, a mom who chose fight over flight, and two brothers who dared to take matters into their own hands.

Eighty seven percent of power wheelchair riders report at least one tip or fall in the past three years. Enter LUCI.

Smart wheelchair technology brought to life to power wheelchairs for stability, security, connectivity and independence.

LINK Product Development helped bring LUCI to life. The LINK design team of mechanical engineers and industrial designers took concepts from sketches all the way to final production units.”

LINK Featured On KOA Radio

In case you missed it, LINK founder Marc Hanchak was interviewed by 850 KOA radio (iHeartMedia with Connor Shreve) to discuss the landscape of product development here in Colorado. Hear what Marc has to say about local design, prototyping, and manufacturing being critical to success.

Feature in Denver Business Journal - LINK and The Quick Company

Denver entrepreneur and design firm link up for new medical device

By Jensen Werley  –  Reporter, Denver Business Journal

Sep 17, 2021

A Denver product development firm has partnered with a Denver-area entrepreneur to invent and produce a new medical device that gives health care providers quick access to their tools.

LINK Product Development worked with Dr. Jack Nguyen, a Denver-based dentist and founder of The Quick Company, to bring a concept designed by Nguyen to life. A full-service product design firm, LINK handles everything including ideation, industrial design, market analysis, feasibility studies, engineering, prototyping and working with manufacturers.

Together, Nguyen and LINK developed the Microtray, a small, molded plastic tray that adheres to surgical gloves and allows medical professionals quick access to tools used during procedures. The Microtray is initially being marketed for dentists and dental assistants.

“It had to be flexible because the hand is not static,” Marc Hanchak, founder of LINK, said of the design the firm settled on for the Microtray. “It had to contour to different-shaped hands and hold a variety of dental tools, gauze and mixing wells.”

LINK developed dozens of prototypes, watching Nguyen manipulate tools to see what might work best in a way that would work for either hand and any-sized hand. Eventually, the team settled on a small diamond-shaped tray with holders for various tools that can adhere to a dentist’s glove.

When LINK works with an inventor, as the design evolves, the firm works with local patent attorneys. The design can be patented if it's novel — and a person might approach LINK with one use in mind, but the design can be patented for additional uses if that comes up. But the client retains 100% of the intellectual property, Hanchak said.

The Microtray is now in the early stages of production. Hanchak said an important tenet of LINK is to bring manufacturing back to Colorado. He said that the Microtray is being injection-molded in the U.S. and that the application of the adhesive backing and packaging is being done in Colorado through Nguyen’s company. As for commercialization, Nguyen said in an emailed statement that they are using small-batch distribution for now and anticipate moving toward large-scale sales efforts in the next two to three months.

“Our state is second to none,” Hanchak said of Colorado and why it was so important to the company to bring manufacturing here. “There’s such a deep history of manufacturing in this state. There’s an amazing talent pool to get things mass-produced. We’re a great alternative for someone who is looking to onshore their manufacturing.”

Behind the Livingston mask

Design of a reusable N-95 mask for the COVID-19 pandemic.

Published in Todays Medical Developments

September 23, 2021
Marc Hanchak & Schuyler Livingston

During the initial and troublesome shortage of personal protective equipment (PPE) that occurred as COVID-19 unfolded in the spring of 2020, our team at LINK found ourselves challenged with designing a reusable N-95 mask for healthcare workers. The goal was aimed at reducing dependency on unstable supply chains and the subsequent shortage of PPE.

What began with a personal connection and passion for lending a hand during a worldwide healthcare crisis, led to a rapid yet thoughtful design project that blended medical device and manufacturing expertise with ingenuity and teamwork.

Opportunity
The opportunity was to design a durable, reusable, and tight-fitting mask surgical mask for frontline healthcare workers as a rapid solution to the critical PPE shortage. Reusability was key, as hospitals and clinics were exhausting supplies of PPE faster than they could be mass produced. Through a series of connections, our team was linked with UC Health, The University of Colorado InWorks program, Make4Covid, and other partners to collaborate on the project.

The initial goal was to develop a mask delivering at least the droplet protection of a surgical mask with a design objective of providing protection against aerosolized viral particles at the N-95 level. From the clinical perspective, the mask needed to be tight-fitting to prevent air from entering other than through the filter to meet the aerosol standard and be comfortable enough to be worn for a prolonged period. According to the stated goal, “The air exchange needed to be adequate for the level of exertion commonly experienced in the clinical environment (ranging from low-intensity sedentary work with the electronic medical record to bursts of high-intensity aerobic exertion during cardiopulmonary resuscitation). It would need to be durable and able to stand up to repeated cycles of decontamination with bleach, alcohol, or disinfectant solution. Finally, the mask design would need to fit within a face shield without excessive fogging. Materials considerations included the need for impermeable materials (other than the filter material itself), biocompatibility, durability, and ability to undergo repeated cycles of disinfection.”

Process
The design process, for what was later coined the Livingston Mask, began by identifying the current challenge or need (lack of reusable N-95 masks for healthcare workers) and important specifications (identified above). This initial discovery process was followed by a series of hand-constructed prototypes and iterations of novel designs.

We began by using silicon molding materials we had on hand to cast an initial mask design within 24 hours of identifying the need. Dissembling other masks used in healthcare settings, experimenting with enhanced versions of the initial design, and casting additional prototypes became the next steps in the process. We used 3D printing to construct the molds required to cast each prototype iteration out of a flexible skin safe thermoset resin.

Once we were connected with a frontline clinician at UC Health, our team was able to test the prototypes in a live setting, secure feedback and turn around an improved design within 24 hours. The rapid-cycle iterative feedback was key in moving the design process forward quickly and with positive improvements. Our team tested a total of seven iterations of the prototype to pass the “qualitative fit test.” The fit test procedure is a requirement put in place by OSHA as a part of a company’s respiratory protection program. This test checks the seal between the respirator face piece and the users face. To detect leakage into the respirator face piece, qualitative fit tests rely on the wearer’s sense of taste or smell as a reaction to an irritant. This is a pass/fail method that relies on whether or not the user detects leakage of the test substance into the face piece. OSHA accepts four qualitative fit test methods:

• Isoamyl acetate, which smells like bananas

• Saccharin, which leaves a sweet taste in your mouth

• Bitrex, which leaves a bitter taste in your mouth

• Irritant smoke, which can cause coughing

We worked through iterations of our prototypes until we consistently passed qualitative fit tests.

Materials
The following components were assembled and used in the initial design of the Livingston Mask.

• Silicon mask chassis

• Top & bottom straps

• Metal disk

• Plastic housing

• Filter material

• Knob

For prototyping, a skin safe product from Smooth-On was utilized. This product is easily mixed and cast using silicone molds. We laser cut and 3D printed plastic components and sourced elastic from Rockywoods Fabrics in Colorado. As the product moved closer to production, we engaged Protolabs in Minnesota to cut tools to injection mold the plastic components. Protolabs also injection molded the mask body in a thermoplastic, medical-grade, flexible material that was compatible with common cleaning solutions used in the hospitals.

Focused Light, a laser cutting service company in Denver, provided the metal disks as a core component of the filter assembly. The straps of the facemask were sourced from a variety of vendors in several design iterations in case of supply chain shortages. The design could use basic buttonhole elastic webbing or even rubber bands if necessary. The filter material was, of course, the most difficult item to source on this list. We worked with a supplier that previously made filter material for other industries and had re-tooled their factory to create N-95 comparable material. We worked directly with this source to create custom disks that would work with this mask, using (and hence wasting) much less material than traditional masks that are single use disposable.

Key learnings
The iterative process for the Livingston Mask, which included initial design and tooling to production of samples, was completed in just over four weeks. The development of a new product from concept to production in a month’s time is unprecedented, however, there were factors which could have accelerated the process and are fruitful lessons for future medical device projects.

Without a design team and suppliers, such as Protolabs and Focused Light, who were all willing to work overtime and weekends to expedite parts, the project could not have been executed within the same timeframe. The filter material suppliers were not able to respond as quickly, and project management of these vendors and assimilation into the cause was quite difficult. Relationships with critical supply chain vendors should have been priority one. This is also the case with normal product development cycles, and apparent in today’s global supply chain situation. It was also evident that the more capabilities the product developer has in house, the better. We are fortunate to have a plethora of 3D printers, a laser cutter, molding capabilities, machining, and welding within our studio. The addition of an injection molding machine, a die cutter, and a few other pieces of equipment would have lessened the project’s dependency on external suppliers. Raw materials could be more quickly processed onsite as opposed to by the vendor and design iterations could have been accomplished even faster.

While the testing phase slowed the project past the critical point of need, we were able to navigate vendor and supply chain issues and collaborate with many team members to rapidly develop an open-source design with an injection mold tool, which lays in wait for subsequent waves of COVID-19, future healthcare crisis or impending medical needs.

GUERRILLA GRAVITY PRESS

Guerrilla Gravity was recently featured by 5280’s Colorado Gear Guide, Bike Magazine, Pink Bike, and others.
